550 HP 347 Windsor Naturally Aspirated — The Honest Parts List

TL;DR: 550 naturally aspirated horsepower from 347 cubic inches is 1.59 horsepower per cubic inch — a materially harder number than the 500 hp 383 Chevy or the 500 hp LS3, and it lands outside what most people mean when they say "street engine." The 347 gets there only by spinning past 6,800 rpm on a rod-to-stroke ratio that does not want to, on compression that does not want pump gas. Before you buy a 347 rotating assembly, price a 363 or a 408W next to it: both make 550 with more margin, less rpm and a longer rod. If you are keeping the 347 anyway, the build is a cylinder head and valvetrain build, and the valvetrain is the part this catalog cannot currently sell you.

What 550 HP Actually Asks of 347 Cubic Inches

Set the arithmetic down first, because it decides everything downstream.

A 347 is a 302 Windsor block bored 0.030 over to 4.030 in and given a 3.400 in stroke crank. That is 347 cubic inches from a block that Ford designed around 3.000 in of stroke. Ask it for 550 hp naturally aspirated and you are asking for 1.59 hp per cubic inch.

That table is the whole argument. The same 550 horsepower is a street number on a 408W and a race number on a 347. Displacement is the cheapest horsepower in the catalog, and on a Windsor it is available — we stock 363 assemblies for the 302 block and 408W and 427W assemblies for the 351W block.

At 1.59 hp/ci naturally aspirated you are committing to roughly 11.5:1 static compression, a 225cc-class intake port, a cam past 250° @ .050, and a power peak north of 6,800 rpm. Check those figures against the parts you actually buy — they are planning brackets, not promises.

The 347's Geometry Is the Problem, Not Its Displacement

This is the part most 347 articles skip.

A 347 uses a 5.400 in connecting rod against a 3.400 in stroke. That is a rod-to-stroke ratio of 1.588. For comparison, a stock 302 runs 5.090 in on 3.000 in for 1.697, and a 408W runs 6.200 in on 4.000 in for 1.550 — worse on paper, but in a block with room for it.

Three consequences follow, and all three cost money at 550 hp:

Mean piston speed. At 6,800 rpm on a 3.400 in stroke, mean piston speed is about 3,853 ft/min. Above roughly 4,000 ft/min, ring, bearing and rod-bolt life start being measured in hours rather than seasons. A 550 hp 347 lives near that line every time you use it.

The wrist pin intrudes into the oil ring. A 3.400 in stroke in an 8.200 in deck block with a 5.400 in rod leaves a compression height near 1.090 in — short enough that the pin bore commonly runs into the oil ring groove, which is why 347 pistons so often need a support rail. It is the geometry, not a defect, but it makes the piston and ring pack specialty items rather than shelf items.

Cylinder wall loading. The short rod increases side loading through the mid-stroke — on a thin-wall production 302 block at 4.030 in bore, the same wall you are asking to hold 11.5:1.

None of this makes a 347 a bad engine. It makes a 347 a 450 hp engine being asked to do a 550 hp job. If nothing forces you onto the 302 block, price the 363 (same block, 4.125 in bore, better bore-to-stroke) or the 351W-based 408W before you buy anything.

Browse rotating assemblies and compare the 347, 363 and 408W kits side by side before committing to a displacement.

The Cylinder Head Sets the Ceiling — and Every Windsor Head Here Is Bare

At 1.59 hp/ci the head is not one decision among many. It is the decision.

550 naturally aspirated horsepower on 347 ci needs roughly 290 cfm at 0.600 in of lift on the intake side, or the cam has to make up the difference in duration. Check that against the casting's published flow data — bore size and test depression both move that figure, and a 4.030 in bore shrouds a large valve more than a 4.125 in bore does.

That puts you in the 205–225cc intake runner class — the top of the Windsor street aftermarket. We list heads from Trick Flow, AFR, Dart, Edelbrock, Ford Performance and ProComp for both the 302 and the 351W:

Two things about that table are honest problems rather than convenient omissions.

Every Windsor head row on this site is sold bare. "Cylinder Head Pair (Bare)" means no valves, no springs, no retainers, no locks, no seals. At 550 hp behind a cam past 250° @ .050 you need a dual spring that controls the lobe at 7,000 rpm, matched to the retainer and to the installed height the head was machined for. That is a spring package, not a part number you guess at.

And the Windsor side of this catalog stocks no valve springs at all — nor retainers, locks, pushrods, lifters or rocker arms. A bare head is the start of a purchase here, and the rest of that purchase is not on our shelf yet.

A second caveat worth naming. The three Trick Flow 302 rows carry identical titles, and so do the three AFR rows. On the Chevy side of this catalog the same class of part reads "AFR Eliminator 210 Cylinder Head — SBC Gen I 350 / 383 Aluminum (65cc, 210cc Intake, Assembled)" — runner volume, chamber volume and assembled state right in the name. The Windsor rows carry brand and engine only. Until they are re-titled, you cannot spec a 550 hp head from this catalog's product titles. Use the manufacturer's casting number and flow sheet, and confirm chamber cc against your target compression before ordering.

Start at cylinder heads and filter by engine family, then verify the casting off-site.

The Camshaft Is a Block-Year Decision Before It's a Spec Decision

This is the Windsor-specific trap, and it is worth more than most of the cam discussion in a 347 article.

Ford put a factory hydraulic roller camshaft in the 5.0L HO beginning in 1985. Blocks before that are flat-tappet blocks with no provision for the roller lifter's spider and dog bones. That single fact splits our Windsor cam catalog cleanly in half:

For the pre-roller block, we list three retrofit hydraulic roller conversion kits that cover 302 and 351W: CPP-FORD-302-RETROFIT-COMPCAMS-01, CPP-FORD-302-RETROFIT-CRANE-02 and CPP-FORD-302-RETROFIT-TRICKFLOW-03. Budget these as part of the cam, not as an accessory — a retrofit roller conversion is the lifters, the link bars, the thrust control and usually a different distributor gear, and it is not optional on a pre-1985 core.

Every other Windsor cam listed under the 302ci and 351W tags is a flat tappet grind — hydraulic from COMP, Crane, Crower, Edelbrock, Howards and Lunati, plus one solid flat tappet from Crower (CPP-FORD-302-CAM-CROWER-15). At 550 hp, behind the spring pressure a 290 cfm head demands, a flat tappet lobe is the wrong tool: the pressure required to control the valve is the pressure that wipes the lobe.

Like the heads, the cam rows are spec-blind — no duration, no lift, no lobe separation angle in any Windsor cam title. Confirm the grind number with the manufacturer, and expect a genuine 550 hp N/A 347 grind near 250–255° @ .050, past .600 in lift, on a 110–112 LSA.

Shop camshafts and timing components together — a cam at this duration deserves a double-roller or billet set, and we list Cloyes, COMP, Melling and Rollmaster for the 302.

The Short Block: Which Rotating Assembly, and the Balance Weight

We list seven 347 rotating assemblies and, importantly, the alternatives beside them:

At 550 hp the assembly is not the place to save. You want a 4340 forged crank, forged rods with a genuine ARP2000-class bolt, and a forged piston with the oil-ring support rail the short compression height requires. Callies, K1 and Molnar sit in that class; the entry-level 347 kits generally do not, and at 6,800 rpm the difference is the rod bolt.

And then the balance weight. Windsor cranks come in 28 oz-in and 50 oz-in external imbalance. Which one your assembly carries decides whether the harmonic damper and flexplate already on the engine are usable or scrap — the single most common way a Windsor build costs money twice. We stock neither, so that is a two-line purchase made elsewhere. Our 347 Windsor stroker cost guide works the balance-weight decision in detail.

Note also: we list no standalone Windsor crankshafts or connecting rods — only complete rotating assemblies and master rebuild kits.

The Honest Gap List

Everything above is buildable except these. Source them before you start rather than discovering them mid-assembly:

1. No Windsor valve springs, retainers or locks. Mandatory at 550 hp, and mandatory anyway because every head we list is bare.
2. No Windsor pushrods, lifters or rocker arms. The retrofit kits include lifters; a factory-roller 5.0 HO block does not get lifters from us.
3. No Windsor head studs. An 11.5:1 N/A engine can live on quality bolts, but studs are the correct part.
4. No harmonic balancer or flexplate. See the balance-weight section — this is the expensive omission.
5. No standalone crank or rods. Rotating assemblies only.
6. Spec-blind titles across every Windsor head, cam and piston row. Runner volume, chamber cc, duration, lift, LSA and compression height are all absent. Verify off the manufacturer's part number every time.
7. Fuel injectors listed only under the 5.0L HO tag, not 302ci. A carbureted 347 sidesteps this; an EFI 347 needs sizing our rows do not state.

What to Buy If You Keep the 347 Anyway

Assuming a 1985-or-later roller block and a carbureted or aftermarket-EFI combination:

• Rotating assembly: Callies, K1 or Molnar 347 — 4340 crank, forged rods, forged pistons sized for 11.0–11.5:1 against your chamber volume
• Rings: Total Seal (CPP-FORD-302-RINGSET-TOTALSEAL-06) — file-fit, and expect the oil ring support rail
• Bearings: Clevite or King HP-class sets from engine bearings
• Heads: 205–225cc aluminum, bare, then assembled with a dual spring package sourced to the cam
• Cam: hydraulic roller, ~250–255° @ .050, on the 5.0 HO roller tag; add a retrofit kit if the block is pre-1985
• Timing set: double roller or billet from timing components
• Intake: single-plane for the rpm this engine will actually use — see intake manifolds
• Oil: high-volume pump from oil pumps, plus a windage tray and more pan capacity than you think
• Gaskets and ignition: MLS head gaskets from gaskets & seals; a distributor and box that will hold timing at 7,000 rpm from ignition components

Be honest with the dyno expectation. On pump gas with a 205cc head, a 347 built this way is a strong 480–510 hp engine. The last 50 horsepower comes from a 225cc-class head, more compression, more rpm and a fuel that tolerates it — the same list that makes it a race engine.

FAQ

Is 550 hp naturally aspirated realistic from a 347? Yes, but not as a pump-gas street engine. At 1.59 hp per cubic inch it requires roughly 11.5:1 compression, a 225cc-class head flowing near 290 cfm, a cam past 250° @ .050 and a power peak above 6,800 rpm. Most 347s advertised at 550 are measured at the crank, or running race fuel.

Would a 363 or 408W make 550 more easily? Considerably. A 408W makes 550 at 1.35 hp/ci — comparable to a 500 hp 383 Chevy — with a 6.200 in rod and less piston speed. A 363 keeps the 302 block but adds bore instead of stroke, which unshrouds the valve. If nothing forces you to keep 347 cubic inches, both are better buys.

What is wrong with the 347's rod ratio? A 5.400 in rod on a 3.400 in stroke gives 1.588:1 — short enough to raise mid-stroke side loading and to push the wrist pin into the oil ring groove, which is why 347 pistons commonly need a support rail. Survivable at 450 hp; a maintenance item at 550.

Can I use a flat tappet cam at 550 hp? No. The spring pressure required to control a valve behind a 290 cfm port at 7,000 rpm is the pressure that wipes a flat tappet lobe. Build a roller engine, and add a retrofit conversion kit if the block is pre-1985.

Does my block year change which camshaft I can buy? Yes, and it is the first question to answer. Ford's factory hydraulic roller starts with the 1985 5.0L HO. Our roller cams sit under the 5.0L HO tag; the 302ci and 351W tags carry flat tappet grinds plus two retrofit roller options for the 351W. A pre-1985 block is a two-purchase job.

Why don't the Windsor head listings show runner volume? They carry brand and engine application only — no runner volume, chamber volume or assembled state — unlike the small-block Chevy rows on this site, which carry all three in the title. Verify the casting number and flow data with the manufacturer before ordering. We have flagged this as a catalog defect.

Are the cylinder heads sold assembled or bare? Every Windsor head row on this site is a bare pair. You will need valves, springs, retainers, locks and seals, and we do not stock Windsor valve springs or retainers — source the spring package to match your cam's lobe and the head's installed height.

What balance weight does my 347 need? It depends on the rotating assembly: Windsor cranks are externally balanced at either 28 oz-in or 50 oz-in. The damper and flexplate must match, and mismatching them is the most common expensive mistake on a Windsor build.

{
