TL;DR: The 5.7 Hemi carries two knock sensors bolted into the lifter valley beneath the intake manifold, which is why a pair of inexpensive sensors turns into a half-day job. The parts are rarely the hard part; the intake manifold removal, the gasket set, the harness pigtails and keeping the valley clean are. Replace both sensors together along with the harness section that connects them, and torque every fastener to the factory service manual value in the factory sequence. Skip the harness or reuse tired gaskets and you will be back under the manifold before the season is out.


Why a 5.7 Hemi sets knock sensor codes in the first place

The Gen III Hemi is a pushrod, overhead-valve V8 with hydraulic roller lifters and a single camshaft in the block. That layout puts a large, open lifter valley under the intake manifold, and that valley is where both knock sensors live - one per bank, threaded into the block casting where they can hear detonation transmitted through the metal.

A knock sensor is a piezoelectric device. It does not measure temperature, pressure or position; it converts the specific vibration frequency of detonation into a small voltage signal that the powertrain control module reads. When that signal disappears, goes out of range or shorts, the module logs a circuit code - typically the P0325 and P0330 family covering the knock sensor 1 and knock sensor 2 circuits - and falls back to a conservative, retarded timing table. The engine still runs. It runs softer, hotter and thirstier, and on a tuned or towing truck it gives up real power.

There are three common root causes on this platform, and only one of them is the sensor element itself:

  • Connector and pigtail failure. The connectors sit in the valley under the manifold, in a warm, sealed space that collects condensation. Corroded terminals and hardened pigtail insulation produce exactly the same codes a dead sensor does.
  • Harness chafe. The short jumper harness that links both sensors to the main engine harness passes across castings and under the manifold. Age plus heat cycles plus vibration equals a rub-through.
  • Actual detonation. Sometimes the sensor is telling the truth. Carbon buildup, low-octane fuel, a lean condition or a cooling problem produce genuine knock, and the module is doing its job.

Diagnose in that order. Sensors and connector hardware for this engine sit under engine sensors, and the rest of the platform's parts live under 5.7 Hemi parts.


What the job actually requires

This is the part most write-ups understate. You are not "changing a sensor." You are removing the intake manifold on a modern V8, which means fuel, electrical and vacuum disconnects, and it means new manifold gaskets going back on.

Stage What it involves Typical shop labour
Access Air intake, throttle body, coil and injector connectors, fuel line, vacuum and PCV lines 0.5 - 1.0 hr
Manifold off Manifold fasteners in reverse sequence, manifold lifted clear, valley covered 0.5 hr
Sensor work Both sensors out, seats cleaned, harness inspected or replaced 0.5 hr
Reassembly New manifold gaskets, all fasteners to spec in sequence, reconnect and verify 1.0 - 1.5 hr

Budget most of a morning if you have done it before, and a full day if you have not. Order the gasket set before you start - discovering you need one with the manifold on the bench is how a Saturday job becomes a Monday job. Manifold and valley sealing parts are grouped under gaskets and seals.

Tools

  • Metric socket set with both deep and shallow sockets, plus wobble or swivel extensions - the rear valley fastener is the one that makes people swear
  • A click-type or digital torque wrench in a low range - the knock sensor fastener spec is small, and a large 1/2-inch drive wrench is the wrong instrument for it - plus a mid-range wrench for the manifold
  • Torx and small hex drivers for the intake and throttle body hardware as fitted to your year
  • Fuel line disconnect tools sized for the quick-connect on your model year
  • A pick set for connector locks, and a small mirror or borescope for looking into the valley
  • Clean lint-free rags and a shop vacuum with a narrow hose
  • Dielectric grease for connectors, plus the factory service manual for your exact model year

Zip ties, loom, terminal grease and small hardware are worth having on the bench before you begin - those pieces are under accessories and hardware.


The sequence that actually works

1. Disconnect the battery and relieve fuel pressure. You are working around injectors and live connectors. Do this first, every time.

2. Photograph everything before it comes off. Vacuum routing, harness clips, ground straps. Ten photographs cost nothing and save an hour of guessing at reassembly.

3. Remove the intake in the factory order. Manifold fasteners come out in the reverse of the tightening sequence, working from the outside toward the centre in stages rather than pulling any one bolt fully at once. The manifold on this engine is a composite part; uneven release warps it.

4. Cover the valley immediately. As soon as the manifold lifts, put a clean rag over every open port. A dropped bolt into an intake runner is an engine-out mistake.

5. Clean before you unbolt the sensors. Vacuum the valley and wipe the sensor seats. You want the mounting faces clean and dry before the new sensors touch them, because a knock sensor reads vibration through metal-to-metal contact - debris under the sensor base changes what it hears.

6. Replace both sensors and the harness together. They are the same age, they lived in the same environment, and the manifold is already off. Doing one and leaving the other is how this job gets done twice.

7. Install dry unless the manual says otherwise. Do not add thread sealant, anti-seize or thread locker to a knock sensor fastener on your own initiative. These sensors depend on a specific clamp load against a clean mounting face, and anything that changes friction at the threads changes the actual clamp load you get at a given torque reading. Follow the factory service manual for your model year.

8. Torque to the manual, in the manual's sequence. The knock sensor fastener is a small bolt with a low specification - low enough that overtightening cracks the sensor body or damages the boss. Set your torque wrench to the value your service manual lists for your year and do not guess from a forum post. The intake manifold has its own multi-pass sequence, tightened from the centre outward in stages to the values the manual gives; that sequence is what makes the manifold seal.

9. Reassemble, reconnect, clear codes, verify. Clear stored trouble codes, start the engine and let it reach operating temperature, then drive it under moderate load. A properly repaired circuit stays quiet. If the code returns immediately, you have a wiring or module-side fault. If it returns after a few days of driving, look at genuine detonation causes rather than the parts you just fitted.


Confirming the repair worked

The satisfying part of this job is that the result is measurable. With a scan tool that reads live data, watch knock retard on a warm engine under moderate throttle. A healthy system holds timing where the calibration wants it and pulls only briefly when it hears something. A system still in fallback shows a flat, conservative timing picture and no meaningful sensor activity at all.

Subjectively, owners describe a truck that "woke up" after this repair. That is not the new sensors adding power; it is the module being allowed back onto its normal timing table after months of running the safe one. Related valvetrain, timing and ignition parts for the whole family sit under Gen III Hemi parts.

One more habit worth building: while the manifold is off, spend ten minutes looking at what else is visible. Valley cleanliness, coolant staining, the condition of the manifold gasket surfaces and any oil residue around the covers all tell you something about the engine's health. The access you paid for with four hours of labour is worth using.


Frequently Asked Questions

Where are the knock sensors on a 5.7 Hemi? Both sit in the lifter valley of the block, underneath the intake manifold - one per bank. There is no way to reach them without removing the manifold, which is why this job takes hours rather than minutes.

Can I just clear the code and keep driving? You can, and the engine will run. It will run on a conservative timing strategy, which costs power and fuel economy, and it leaves you without knock protection if a real detonation problem develops later. On a truck that tows, fix it.

Should I replace both sensors or just the one that set the code? Both. They are the same age in the same environment, and the manifold is already off. The second sensor is a small marginal cost against repeating the entire access job.

Do I need to replace the harness too? On higher-mileage examples, plan on it. The connectors and pigtails down in the valley fail as often as the sensor elements themselves, and a new sensor plugged into a corroded connector reproduces the original fault exactly.

What torque do the knock sensors take? The specification is low, and it varies by model year and casting. Look it up in the factory service manual for your exact vehicle and use a torque wrench that reads accurately at the bottom of its range. Overtightening cracks the sensor; undertightening leaves it unable to hear the block properly.

Will new knock sensors fix an engine that is genuinely detonating? No. If the sensors are working and the module is pulling timing, it is reporting a real condition. Look at fuel octane, carbon buildup, cooling system performance and any aftermarket tune before assuming the sensors are at fault.


Sources

Written from the Core Powertrain Parts technical team's shop experience with Gen III Hemi engines, the diagnostic logic of OBD-II knock sensor circuit codes, and general piezoelectric knock sensor operating principles. Year-specific torque values, fastener sequences and current part numbers must be confirmed against the factory service manual and the manufacturer catalogue for your exact vehicle before the job.
