TL;DR: The 6.7L Power Stroke uses a gerotor-style oil pump mounted at the front of the engine and driven directly off the crankshaft. That location, not the part itself, is what makes this decision expensive — the pump is buried behind the front cover on a very crowded end of a very heavy engine. Because the aftermarket for this specific pump is thin, the honest answer to "which brand" is an OE or genuine OE-equivalent unit from a supplier that will stand behind it. The decision that actually saves you money is made before you order: prove the pump is the fault, and plan what else gets replaced while the front of the engine is open.

Why this is a labour decision before it is a parts decision

On a lot of engines, an oil pump is a pan-off job. Drop the sump, unbolt the pump, fit the new one, done in an afternoon. The 6.7L Power Stroke is not that engine.

Ford's 6.7 — the Scorpion — carries its oil pump at the front, turned directly by the crankshaft. To reach it you are working through the front of the engine, and the front of this engine is the busy end: the accessory drive, the cooling system plumbing, the fuel system drive and the timing drive all live there. On a truck, that usually means removing a substantial amount of front-end hardware to get clearance, and on many shop estimates it is more practical to pull the cab or the engine than to fight it in place. Confirm the approach your service information specifies for your exact chassis and model year before you commit, because a Super Duty, a chassis cab and a medium-duty truck do not present the same access.

The consequence is simple arithmetic. The pump is a modest fraction of the total; the hours are the bill. Shops commonly quote this as a multi-day job rather than a multi-hour one. That changes what "best" means. When the labour dwarfs the part, buying the cheapest available pump to save a small percentage of the total is a bad trade — you are risking the entire labour bill to shave a sliver off the parts line.

Everything for this engine family lives under 6.7 Power Stroke parts, and the pump category itself is oil pumps and pickups.

Prove it is the pump first

More 6.7 oil pumps get replaced than actually fail. Low oil pressure — a warning lamp, a low gauge reading, a stored pressure-related code — is a symptom with a long list of causes, and the pump is near the bottom of that list by frequency. Work the cheap causes first, in this order.

The oil itself. Wrong viscosity, overdue oil, or oil diluted with fuel will all drop indicated pressure, particularly hot at idle. Fuel dilution is worth taking seriously on any modern diesel that does frequent regeneration cycles or short trips. Pull a sample, smell it, and if there is any doubt send it for analysis before you spend anything. Use the grade and specification the owner's manual calls for, and change it on the interval in that manual — not on a number you read on a forum. Oils and service chemicals are in oil, coolant and additives.

The sensor and the wiring. An engine oil pressure sensor that has drifted, or a corroded connector, will report a pressure the engine does not actually have. This is a common and comparatively cheap fault. Before anything comes apart, verify indicated pressure against a mechanical gauge plumbed into the engine. If the mechanical gauge is healthy and the dash is not, your problem is electrical. Sensors are under engine sensors.

Restriction in the oil circuit. A clogged filter, a bypassing filter, a restricted oil cooler or a pickup screen partly blocked with sludge or debris will all starve the system while the pump itself is perfectly serviceable. On any engine that has had a previous internal failure, assume debris until proven otherwise. Cooler assemblies are under oil coolers.

Bearing clearance. This is the one people do not want to hear. Worn rod and main bearings increase leak-down through the clearances, and the pressure falls even though the pump is moving its rated volume. The tell is pressure that is worst hot and at idle and recovers with revs, usually alongside mileage or a history that makes wear plausible. If the bearings are the cause, a new oil pump fixes nothing — you are looking at an engine job. Bearing sets are under rod and main bearings.

Only when oil, sensor, restriction and bearing clearance have all been ruled out does the pump become the prime suspect.

What actually makes one pump better than another

Once you have decided the pump is coming out, here is what separates a good replacement from a gamble.

Notice what is absent from that table: horsepower claims, colour, and "high volume" marketing. A stock 6.7 does not need more oil volume; it needs the volume Ford designed the galleries and clearances around. A pump that moves more oil than the system was designed to pass raises drive load and can push more oil past the relief than the circuit benefits from. Unless you are building a purpose-specific engine with clearances opened up on purpose, matching the original specification is the right target.

What to replace while you are in there

This is where you either save money or leak the labour bill back out in six months. The front of this engine is open exactly once. Everything on this list is inexpensive relative to going back in.

• Every seal and gasket the front cover disturbs. Front cover gasket, crankshaft front seal, and any O-rings the procedure calls out. Reusing a crank seal because it "looked fine" is how a clean job turns into a repeat job. Start in gaskets and seals.
• The oil pressure sensor. It is cheap, it is right there in the diagnostic path, and a marginal one will have you second-guessing a fresh pump.
• The oil cooler, if the oil has been contaminated. If a failure put debris into the oil, the cooler holds it and feeds it straight back to the new pump.
• The filter and a full fluid change, obviously — and a second early change after a short run-in interval if the system had any contamination in it.
• Coolant and accessory hardware you had to disturb to get access. Belts, tensioners and hoses that are already off and already aged should not go back on.

Before reassembly, prime the system the way the service procedure specifies, and verify pressure on a mechanical gauge on first start rather than trusting the dash. Torque every fastener in the factory sequence to the value in the service manual — the front cover and pump fasteners on this engine are not a "snug it up" proposition, and several are torque-to-yield or single-use in many procedures. Confirm the current part number for any component against the manufacturer catalogue for your exact model year before ordering, because Ford revised parts across the 6.7's production run.

Broader diesel coverage is under diesel engine parts and the full Ford range under Power Stroke parts.

Frequently Asked Questions

Where is the oil pump on a 6.7 Power Stroke? At the front of the engine, driven directly off the crankshaft, behind the front cover. It is not a pan-off, sump-mounted pump, which is why access dominates the job.

Can I replace the 6.7 Power Stroke oil pump without pulling the engine or cab? Sometimes, depending on chassis and model year, but it is a tight job either way. Many shops find it faster overall to gain full access rather than fight the front of the engine in place. Check the procedure your service information gives for your specific truck before planning the work.

Does low oil pressure always mean the pump is bad? No, and usually it does not. Diluted or wrong-grade oil, a faulty pressure sensor, a restricted cooler or filter, a blocked pickup, or worn bearings all produce the same symptom. Verify with a mechanical gauge before condemning the pump.

Is a high-volume oil pump worth it on a 6.7 Power Stroke? For a stock or lightly modified engine, no. The oil system was designed around a specific flow and set of clearances. Match the original specification unless you are building an engine with deliberately altered clearances and you know why.

What should I replace at the same time as the oil pump? Every gasket and seal the front cover disturbs, the crankshaft front seal, the oil filter and a full oil change, the oil pressure sensor, and the oil cooler if the oil was contaminated. Also any belts, hoses or tensioners you had to remove that are already aged.

How do I know if the problem is worn bearings instead of the pump? Bearing-related pressure loss is typically worst when the engine is hot at idle and improves with engine speed, and it usually comes with high mileage or a hard-use history. Oil analysis showing bearing material is a strong signal. A new pump will not restore pressure lost through excessive bearing clearance.

What oil should go back in after the job? The grade and specification listed in your owner's manual for your model year, changed on the manual's interval. On a fresh pump after any contamination event, a short first interval followed by an early change is cheap insurance.

Sources

• Ford owner's manual and service information for the 6.7L Power Stroke — the authority for oil grade, capacity, service intervals, torque figures and the access procedure for your specific chassis and model year.
• Manufacturer catalogues for current part numbers and application coverage; part numbers were revised across the 6.7's production run and must be confirmed against your VIN and model year.
