How to Install a Cam in an LS Without Pulling the Radiator

TL;DR: An LS camshaft is longer than the gap between the front cover and the radiator, which is why every stock procedure starts with draining the cooling system and opening the A/C. You can skip both by unbolting the radiator core support and sliding the whole front clip forward as an assembly, leaving the radiator hoses connected and the condenser lines charged. That saves a coolant drain and an A/C evacuation-and-recharge, and it changes nothing about the rest of the job. The parts of an LS cam swap that actually go wrong are lifter retention, cam sensor location, VVT, and pushrod length — not the cam.

Why the radiator is in the way at all

The camshaft comes out the front of the block, through the cam bore, in a straight line. On a Gen III or Gen IV LS the cam is roughly the length of the block, and once the front cover is off, that whole length has to travel forward before the rear journal clears its bore. In a truck or an F-body with the engine still in the chassis, the space in front of the timing cover is occupied by the fan, the shroud, the radiator, and the A/C condenser, in that order.

The conventional answer is to remove them. That means draining the cooling system, and on any vehicle with working air conditioning it means disconnecting condenser lines — not a wrench job. Refrigerant must be recovered with a machine before the system is opened, then evacuated and recharged afterward: a shop visit at each end of a job otherwise being done in a driveway.

The alternative is to move the obstruction instead of removing it.

The three access paths, compared

Pulling the radiator is the honest default when the engine is out of the vehicle, when the cooling system is due anyway, or when the A/C is already empty. There is nothing wrong with it.

Sliding the core support is the method this guide covers. On most GM trucks and SUVs the radiator, condenser, transmission cooler, and fan shroud all ride on one removable core support bolted to the frame rails. Remove the grille, headlights, and front fascia hardware, pull the core support fasteners, and the entire assembly moves forward several inches as a unit — hoses attached, refrigerant sealed. That is almost always enough clearance to walk the cam out.

Angling the cam past the corner of the radiator is the method to be careful with. It occasionally works in a generous engine bay with the fan and shroud out, and it is also how cam bearings get scored: a camshaft withdrawn at an angle drags its lobes across four or five bearing shells on the way. The bearings are soft, the lobes are hardened, and the damage stays invisible until an oil pressure problem shows up later. If the cam does not slide straight, make more room rather than more angle.

Before anything comes apart: get the parts list right

More LS cam swaps are ruined at the ordering stage than on the driveway. Four decisions are made before a wrench is picked up.

Lifters are not optional on a used engine. A hydraulic roller lifter wears in against the lobe it has been riding. Put old lifters on a new cam and both surfaces are working against a mating profile they have never seen. On an engine with real mileage, lifters go in with the cam — and if it has ever ticked, read LS lifter failure before assuming a cam alone fixes it.

Springs are decided by the cam's lift, not by preference. Factory LS springs run out of travel well before an aggressive aftermarket lobe does, and coil bind ends a cam swap violently. Match the valve springs to the cam card's lift figure and to the retainer and seal stack already on the head.

Gen IV means AFM and possibly VVT. A Gen IV truck engine with Active Fuel Management has a valley full of AFM lifters and a lifter oil manifold assembly that a non-AFM cam does not support — a delete job with its own parts and its own tune, covered in the LS AFM delete guide and stocked under AFM delete. Separately, a Gen IV VVT engine carries a cam phaser on the nose of the cam. Either buy a VVT-specific cam and keep the phaser, or buy a VVT delete package with the correct timing set, cam bolt, front cover provisions, and tune. Ordering a plain non-VVT cam for a VVT engine and finding out in the driveway is a common, expensive stall.

Cam sensor location changed between generations. Gen III 24x engines carry the camshaft position sensor at the rear of the block; Gen IV 58x engines moved it into the front cover. Different parts, chosen by the engine rather than by the cam. Both are stocked under sensors — order the right one now, while the front of the engine is coming apart anyway.

Cam selection itself — brand, lobe family, LSA, and what actually suits a truck versus a car — is covered in the LS cam brand comparison, and what the whole job typically consumes is broken down in the LS cam swap cost guide. Browse camshafts and cam stage kits, then confirm your engine on the fitment lookup.

The procedure

1. Disconnect the battery and relieve fuel pressure. The intake manifold and fuel rail are coming off. Do this first, not later.

2. Remove the front accessory drive and the fan. Belt, tensioner access, fan and clutch, shroud. On a truck with a mechanical fan this is also the point where you find out whether the fan clutch was failing.

3. Slide the core support forward. Grille, headlights, and fascia hardware come off, then the core support fasteners. Move the assembly forward as a unit with the radiator hoses and condenser lines still attached, and support it so nothing hangs by a line. Strap it in its forward position rather than trusting it to stay there. If a transmission cooler line or a hood latch cable is the only thing fighting you, that single item can usually be unbolted and moved rather than disconnected.

4. Top end: intake, valve covers, rockers, pushrods. Take the rockers off in order and keep the pushrods in order — they are not identical once worn in, and a reused pushrod should go back to the lifter it has been living on. With the rockers off, this is the moment to fit a trunnion upgrade if the engine still has factory rockers: no extra labour now, a full teardown later.

5. Deal with the lifters before the cam moves. This is the step that turns a weekend into a week. With the heads still on, nothing holds the lifters up once the cam is gone. A lifter that drops out of its plastic tray lands in the valley or — worse — wedges below the tray, and the tray cannot then be lifted out without pulling the head. Options, in order of reliability: remove the lifters and trays entirely through the valley with the intake off, which is the correct approach anyway if the lifters are being replaced; hold each lifter up with a retaining tool or a strong magnet through the pushrod hole; or secure the lifters into their trays first. Whichever you choose, choose it before the cam sprocket comes off.

6. Front cover off. The harmonic balancer comes off first, and on an LS it is an interference fit on the crank snout — puller to remove, proper installer to go back on. There is no hammer version of this step. The front cover also seals to the front of the oil pan, so the front pan bolts are loosened before it will come away cleanly, and the cover gasket and crank seal are replaced rather than reused. Pull those from gaskets and seals with the rest of the order.

7. Timing set off, cam retaining plate out. Rotate the engine to line up the timing marks and note their position first. Remove the cam sprocket and chain, then the three bolts holding the cam retaining plate behind it. A new timing set goes on with a new cam as a matter of course — the old chain has worn in against the old sprockets.

8. Walk the cam out. Thread a long bolt or a cam installation handle into the nose of the cam so you have something to hold that is not a lobe. Support the weight and draw it straight out, slowly. The cam should never touch a bearing surface on the way. If it binds, stop and find more clearance.

9. Cam in, lubricated correctly. Coat the lobes with the assembly lube supplied with the cam — the moly-based lube the manufacturer specifies, not engine oil — and the journals with clean oil. Feed it in on the same handle, level and slow.

10. Reassemble and torque the cam bolt. Retaining plate, timing set with marks aligned as noted, cam bolt to specification. Take the cam bolt torque figure from the service data for your engine year and check whether the factory bolt is single-use — an ARP cam bolt set is the usual replacement and is stocked in the catalog.

11. Check pushrod length before the rockers go back on. A new cam with a different base circle changes the geometry between lifter and rocker. Factory-length pushrods usually work with mild cams and usually do not with aggressive ones. A length checker settles it in an afternoon; guessing produces either lifter preload that never bleeds down or a rocker running at the wrong angle across the valve tip. Correct-length pushrods are cheap next to a second teardown.

12. Fill and tune. Reassemble the top end with new gaskets, refill and burp the cooling system, refit the core support and fascia, and get the engine tuned. A cam changes airflow across the entire rev range and the factory calibration does not know about it. On a Gen IV, a VVT or AFM change is not optional to tune.

Reference: what the job consumes

FAQ

Can I really do an LS cam swap without opening the A/C system? Yes, on most GM trucks and SUVs, by sliding the core support forward as an assembly instead of removing the radiator and condenser individually — the refrigerant lines stay connected and sealed. Clearance varies by chassis, so confirm the core support actually moves before committing to the method.

Do I have to drain the coolant? With the core-support method, usually not; the hoses stay attached. Expect to lose a small amount regardless, and if the water pump comes off for any reason the system is open and should be drained properly.

Do I need new lifters with a new cam? On any engine with meaningful mileage, yes — hydraulic roller lifters wear in against their specific lobes. On a very low-mileage engine, reused lifters returned to their original positions are more defensible, but a cam swap is the cheapest moment to replace them.

How do I keep the lifters from falling when the cam comes out? Decide before the cam moves. The most reliable approach is removing the lifters and trays through the valley with the intake off — which you are doing anyway if they are being replaced. Otherwise hold them with a retaining tool or magnets through the pushrod holes. Recovering a lifter wedged under a tray can mean pulling a cylinder head.

Can I put a non-VVT cam in a Gen IV VVT engine? Only as part of a complete VVT delete: the correct non-VVT timing set, cam bolt, front cover provisions, and a tune that stops the ECM commanding a phaser that is no longer there. Fitting the cam alone will not work.

Do I need to degree the cam? Not for most street swaps installed on a straight-up timing set. Degreeing matters when the cam card specifies an intake centerline the timing set does not deliver, or when a keyway-adjustable set is being used to add advance deliberately.

Will factory-length pushrods work? Sometimes, and often not. The answer comes from a length checker after the cam is in, not from what worked on someone else's engine. Wrong-length pushrods produce incorrect lifter preload, which is what turns a fresh cam swap into a noisy one.

Does a hydraulic roller cam need a break-in procedure? Not the twenty-minute high-idle break-in a flat tappet cam requires — a roller does not need to wear a pattern in. It still needs correct assembly lube on installation and an unhurried first start with oil pressure confirmed before revving.
